AP4830 DC Programmable Up or Down Ramp Generator
Brand: EurothermModel AP4830 is useful in controlling process equipment requiring voltage or current ramp control.
Typical applications include temperature cycling, PID controller setpoint control, motor control and bumpless control transfer.
Features- Adjustable Ramp Rate & Setpoint
- Built-in Reference Supply for External Programming
- TTL Setpoint Status
- Easy Plug-in Installation/ Low Mean-Time-to-Repair
- AC Line Powered
Displaying prices & availability for Ohio, United States in CAD. Change location.
Models matching criteria: 2
Specifications
Brand
Capacitance
- 10 to 470 µF
Consumption
- Power Consumption: 3 W Typical
- Power Consumption: 5 W, Max.
Electrical Connectors
- 20-Pin
Load
- 10 mA - Max.
Operating Temperature
- 0° to 60° C (32° to 140° F)
Output
- 0-10 V
- 0-20 mA
- 10 V, Max.
- 50 mA - Max.
- Current: 15 V Compliance at 20 mA (750 ohms, Max.
- Drive (Voltage): 10 mA - Max.
Output Impedence
- Current Output: > 100 kiloohms
- Voltage Output: < 10 ohms
Power
- 120 Vac (± 10 %, 50-400 Hz)
- Available: 240 Vac (± 10 %, 50-400 Hz)
Repeatability
- Within 1 % of Previous Ramp or Set Point Setting
Response Time
- Base Rate (Fastest): 1 to 245 seconds
Span & Zero Adjustments
- ± 3 %
Stability
- < 0.003 %/°C
- 15-minute Warm-Up: ± 0.05 %/°C Typical
Storage Temperature
- -20° to 85° C (-4° to 185° F)
Supply Voltage
- Reference Supply: 5 Vdc ± 5 %
